PAT RED > ROLLING SHUTTER DOOR > RDJ600 |
คุณสมบัติ |
– มอเตอร์สำหรับประตูม้วนไฟฟ้า สามารถประยุกต์ใช้งานได้หลากหลายแบบ ไม่ว่าจะเป็นประตูโรงรถ หรือประตูโรงงาน
– รองรับประตูม้วนได้ถึง 600 กก.
– ขับเคลื่อนด้วยมอเตอร์แบบ 220V AC
– มอเตอร์ทำงานเสียงเบา และสั่นสะเทือนน้อย
– ติดตั้งง่าย น้ำหนักเบา
– เปิด-ปิดด้วยมือได้เมื่อไฟดับ
– ในชุดประกอบไปด้วยมอเตอร์ แผงคอนโทรล และรีโมท 2 ตัว
Product Features |
– Roller shutter motor for sectional doors and roller shutter doors. Can be installed as automations for garage door and industrial doors.
– Supports door weight up to 600 kg.
– 220V AC motor
– Low noise operation with little vibration
– Easy to install with small and lightweight design
– Manual operation available for power outage
– Set includes motor, control panel and 2 pieces of remote controls
Model | RDJ600 |
Input Voltage(V) | 220Vac +- 10%/50Hz |
Input Power(W) | 370W |
Output Torque(N.m) | 412N.m |
Max. Lift(Kg) | 600Kg. |
Sprocket Output Side/Drum Side | #50 T9/T47 |
Rotate Speed(r/min) | 4.4r/min |
Max. operating range(high:m) | 6m |
Roll(inch) | 5" |
Chain (ANSI Standard) | 10A |
IP Grade | 44 |
Brochure – Automatic Rolling Shutter Door RDJ-600
