PAT RED > Swing Gate Automation > BFT > GIUNO ULTRA BT A |
ขับเคลื่่อนด้วยระบบไฮดรอลิคแบบแขนทรงกระบอก รองรับน้ำหนักประตูสูงสุดที่ 800 กิโลกรัม และความกว้างประตูสูงสุดที่ 5.0 เมตร
Hydraulic piston arm gate operator Suitable for gates with max. weight of 800 kg and max. gate width of 5.0 m
คุณสมบัติ |
– เป็นมอเตอร์ประตูบานสวิงอัตโนมัติแบบแขนทรงกระบอก เหมาะสำหรับที่อยู่อาศัยหรือโรงงานที่มีการใช้งานหนัก
– ขับเคลื่อนด้วยมอเตอร์ 24V DC ด้วยระบบไฮดรอลิก (Hydraulic)
– เพิ่มความปลอดภัยด้วยระบบ D-Track ช่วยตรวจจับสิ่งกีดขวางและหยุดหรือถอยประตูกลับเพื่อไม่ให้ชนสิ่งกีดขวางนั้นๆ
– สามารถเพิ่มแบตเตอรี่สำรองได้ เพื่อใช้งานเมื่อไฟดับ (อุปกรณ์เสริม)
– สามารถเพิ่มอุปกรณ์เสริมอื่นๆตามความต้องการ นอกเหนือไปจากรีโมท เช่น สวิตช์ติดผนัง คีย์แพด โฟโต้เซลล์ ไฟหัวเสา เป็นต้น หรืออุปกรณ์เสริมเพื่อสั่งงานผ่านโทรศัพท์มือถือ
– สินค้านำเข้าจาก ประเทศอิตาลี 🇮🇹
Product Features |
– Piston arm gate operator suitable for very intensive use for both residential and industrial use
– Hydraulic operator with 24V DC motor
– Exclusive BFT ‘D-Track Technology’ allows the automatic gate openers to detect obstacles and then stop or reverse the movements of the gate in order to ensure safety
– Battery set available for emergencies (optional)
– Recommended accessories other than remote controls include wall switches, keypads, photocells, flashing lights etc. or through mobile applications (optional)
– Imported from Italy 🇮🇹
GIUNO ULTRA BT A50 | |
Power supply | 230 V |
Motor supply | 24V DC |
Rated power | 90 W |
Max. gate weight | 800 kg |
Max. gate width | 5.0 m |
Max. opening angle | 110° |
Opening/Closing time | 20 s |
Operation | Hydraulic |
Limit switch | Magnetic |
Slowdown | Yes |
Locking | Electric Lock |
Protection rating | IP55 |
Operating temperature | -20°C to +60°C |
อัพเดตข้อมูล : 24/11/2021
